Solar Interlock Kit KS-6513

This Interlock Kit mounts to EATON electrical panels with the following features:

• SOLAR & GENERATOR COMPATIBLE INTERLOCK KIT
• Space between breaker columns: 1/2"
• Gap between main breaker and columns below: 1 1/4 - 1 1/2"
• 150-200 amp main breaker
• Main breaker toggle action: horizontal (left-right) throw direction
• Eaton BR branch breakers

Requirements:

• Install a generator breaker at the top of the right column: spaces 2 & 4
• Install a solar breaker in the bottom left corner of the branch circuit columns
• Compatible with 30 space 60 circuit panels. 15 1" spaces in the left column & 15 1" spaces in the right
• Front page of the installation instruction includes a list of included components

Modified versions of this Interlock Kit exist, see: KS-6512, KS-6514 (solar modified Interlock Kit) call for more details about modified kits: (804) 726-2448

Kit Installation Instructions
